| 名称:BS Fused Terminal - screwless wire clamp FTB1.4.11 FTC2,11series |
| 型号: |
| 类别:端子台 |
| |
|
|
|
| 详细介绍： |
|
|
-
Terminal strip with fuse-holder
-
In compliance with BS-EN 60598-1
-
For 6 x 25mm fuse
-
With or Without earth screw
-
Choice of mounting base / leg anti-rotation spigot
-
Standard color -white
| |
|
| |
| Technical Data |
|
| Housing |
Polycarbonate |
| |
|
94V-2 grade |
| Insert |
brass |
| Terminal screw |
M3.5 x 7.5 zinc-plated steel |
| Earth screw |
M3.5 x 12 zinc-plated steel |
| Voltage / Ampere |
250V / 13A |
| |
|
| Temperature |
|
| |
working |
-20oC to 120oC |
| |
short time |
160oC |
| Cross section |
0.75 - 2.5mm2 |
| AWG |
20-14 (with wire protector) |
| |
|
|
| Packing |
|
|
| FTB 1 4 11 |
|
500pcs per ctn. |
| FTC 2 11 |
|
300pcs per ctn. |
| | |
|
