| 名称:Fuse Terminals |
| 型号: |
| 类别:端子台 |
| |
|
|
|
| 详细介绍： |
|
|
| |
|
| |
| Technical Data |
| Housing |
Polyamide 6/6 |
| |
94V-2 grade |
| Insert |
brass, nickel plated |
| Wire protector |
stainless steel |
| Screw |
M3x6, yellow chromated |
| Earth screw |
M3x14, yellow chromated |
| Voltage / Ampere (IEC) |
|
| |
terminal strip |
400V / 15A |
| |
fuse carrier |
250V / 6.3A |
| Voltage / Ampere (UL) |
|
| |
terminal strip |
200V / 15A |
| |
fuse carrier |
200V / 10A |
| Temperature |
|
| |
working |
-40oC to 100oC |
| |
short period |
140oC |
| Cross section |
2.5mm2 |
| AWG |
14 |
| |
| Packing |
| 540-1WP |
100x10 per ctn |
| 540-2WP |
70x10 per ctn |
| 540-3WP / 3GWP |
50x10 per ctn |
| 540-4WP / 4GWP |
40x10 per ctn |
| 540-5WP / 5GWP |
40x10 per ctn |
| |
| |
| |
|
